60Hz 50Hz 100kVA 500kVA 1000kVA 3 Phase Cummins electric Silent
Diesel Power Generator
| Frequency: 50HZ;Rotating speed: 1500Rpm |
| Model | Power(KW) | Capacity(KVA) | Rated current(A) | Engine Model | Stamford Type |
| BS-C25 | 20 | 25 | 36 | 4B3.9-G1 | BS184F |
| BS-C40 | 32 | 40 | 57.7 | 4BT3.9-G2 | BS184J |
| BS-C70 | 56 | 70 | 101 | 4BTA3.9-G11 | BS224G |
| BS-C85 | 68 | 85 | 122.7 | 6BT5.9-G1 | BS224G |
| BS-C120 | 96 | 120 | 173.2 | 6BTA5.9-G2 | BS274D |
| BS-C140 | 112 | 140 | 202 | 6BTAA5.9-G2 | BS274E |
| BS-C160 | 128 | 160 | 230.9 | 6CTA8.3-G1 | BS274F |
| BS-C275 | 220 | 275 | 396.9 | NTA855-G1A | BS314D |
| BS-C350 | 280 | 350 | 505 | NTA855-G2A | BS314E |
| BS-C400 | 320 | 400 | 577.4 | NTAA855-G7A | BS354C |
| BS-C450 | 360 | 450 | 649.5 | KTA19-G3 | BS354C |
| BS-C500 | 400 | 500 | 721.7 | KTA19-G4 | BS354D |
| BS-C600 | 480 | 600 | 866 | KTAA19-G6 | BS354E |
| BS-C750 | 600 | 750 | 1082.6 | KTA38-G2 | BS404B |
| BS-C800 | 640 | 800 | 1154.7 | KTA38-G2B | BS404C |
| BS-C900 | 720 | 900 | 1299 | KTA38-G2A | BS404D |
| BS-C800 | 800 | 1000 | 1443.4 | KTA38-G5 | BS404E |
| BS-C1250 | 1000 | 1250 | 1804.3 | KTA50-G3 | BS404G |
| | | | | |
| Frequency: 60HZ;Rotating speed: 1800Rpm |
| Model | Power(KW) | Capacity(KVA) | Rated current(A) | Engine Model | Stamford Type |
| BS-C29 | 23 | 29 | 41.5 | 4B3.9-G1 | 184E |
| BS-C43 | 34 | 43 | 61.3 | 4BT3.9-G1 | 184H |
| BS-C63 | 50 | 63 | 90.2 | 4BTA3.9-G2 | 224D |
| BS-C80 | 64 | 80 | 115.5 | 4BTA3.9-G11 | 224F |
| BS-C94 | 75 | 94 | 135.3 | 6BT5.9-G2 | 224G |
| BS-C125 | 100 | 125 | 180.4 | 6BTA5.9-G2 | 274D |
| BS-C150 | 120 | 150 | 216.5 | 6BTAA5.9-G2 | 274E |
| BS-C188 | 150 | 188 | 270.6 | 6CTA8.3-G2 | 274F |
| BS-C250 | 200 | 250 | 360.9 | NT855-GA | 274J |
| BS-C394 | 315 | 394 | 568.3 | NTA855-G3 | 314E |
| BS-C438 | 350 | 438 | 631.5 | KTA19-G2 | 314F |
| BS-C513 | 410 | 513 | 739.8 | KTA19-G3 | 354C |
| BS-C625 | 500 | 625 | 902 | KTAA19-G5 | 354D |
| BS-C688 | 550 | 688 | 992.3 | KTAA19-G6A | 354E |
| BS-C775 | 620 | 775 | 1118.6 | KT38-G | 354F |
| BS-C906 | 725 | 906 | 1308 | KT38-G2 | 404C |
| BS-C1000 | 800 | 1000 | 1443.4 | KT38-G2A | 404D |
More specific parameters to choose.
(1)The silent canopy we use cold-rolled sheet, all positions are
stronger.
(2)Our spraying plastics all go through pre-treatment of pickling
and phosphating,
so that the surface of the painting will not change color even if
placed outside for five years.
(3)Canopy color painted by customer's requirement.
(4)Strict test including 50% load,75% load,100% load and 110% Load
.
(5)Forklift mouth in base frame for easy loading and discharging.
(6)Logo made by customer's requirement if order quantity ≥10units
or a full container.
Q: Do you offer OEM service?
A: Yes
Q: What is your payment term?
A: 30% T/T in advance, the rest payment before shipment. Or
irrevocable L/C.
Q: What is your lead time?
A: About 30 days after receiving deposit or original L/C.But if
your order with some special design,
then the delivery time is longer.
Q: What certificates do you have?
A: We have CE, ISO. And we can apply for specific certificate for
different country such as SONCAP
for Nigeria,CIQ for Egypt, SASO for Saudi Arabia, etc
Q:What is your MOQ?
A: Above 1pc
Q. Which port do you often use when export?
A: Fuzhou Port, or as customer request.
Q.How to choose the power?
A.:Collect all power of your equipments,take the current into your
consideration.
Q.What is the difference between Prime power and Standby power?
A.:Prime power is 12hours continous power,one hour 10% over load in
every 12 running hours is allowed.
Standby power is the limit value of maximum output for emergency
use. Overloading is prohibited
Q.What about the warranty
Guarantee for one year or 1000 hours (accord to whichever reach
first) from ex-factory date.During the
guarantee period,our company will provide the free easy damaged
spare part for problems caused by our
