50Hz Quanchai Water Cooling Silent Power Generator 380V Diesel
20kva
Basic Configuration
1 . Exhaust silencer 2 . Flexible pipes 3 . Starting battery 4 .
Starting Charger 5 . Cooling radiator
6 . Battery Wires 7 . Base frame 8 . Main circuit breaker 9 . AVR
10 . Manual books 11 . Control box
12 . Switch-box 13 . Genset wooden
Engine :
Mechanical / Electric governing starting method
Nature / Turbocharged after water cooled intaking Method.
Closed water cooled system
Electric Starting
Forged steel crankshaft, cast iron cylinder and replaceable wet
type cylinder liner
Low Consumption
Alternator :
Brand : Stamford or Leroysomer or our BOSS series brushless
Rated output : 12 - 184kW
Rated voltage : 400 / 230V, 380 / 220, 220 / 110, etc
Rated Frequency : 50 / 60Hz
H class insulation
Voltage regulation : AVR automatic
1.0% voltage regulation (max.) in static conditions
Protection class : IP 22 or IP23
Quanchai Engine :
Quanchai Generator sets seriers diesel engine has always been an
excellent seriers of diesel quality,
the use of direct injection combustion chanber,easy to start,low
fuel consumption,economy,compact structure,
light weight,easy to install layout.With strong motivation,small
vibration,low noise,the performance advantage
of low transfer rate.The key components are optimized for
high-speed automotive diesel engine parts and
components,so that diesel has a good reliability.Dynamic interface
is in line with the SAE standard,having a
good market interchangeability and versatility.Electronic governor
of selective installation makes revolving
speed much stable.
| Genset Model | BS-QC20 |
| Rated Output (KW/KVA) | 16KW/20KVA |
| Max Output (KW/KVA) | 17.6KW/22KVA |
| Phase | 3 |
| Power Factor (cos Ø) | 0.8 |
| Frequency | 50HZ/1500RPM |
| Rated Voltage (V) | 400V |
| Rated Current (A) | 28.8A |
| Silent Genset Dimensions (MM)--N.W(KGS) | 2080*990*1210--880KGS |
| Engine | Model | QC490D |
| Type | 4-cycle, direct injection, In line, Water cooling |
| Cylinder Numbers | 4-cylinder |
| Rated Power (KW) | 20KW |
| Standby Power(KW) | 22KW |
| Air intake type | Natural Intake |
| Combustion Chamber Type | Direct Injection |
| Displacement(L) | 2.672 |
| Starting Type | Electric starting |
| Bore×Stroke (MM×MM) | 90x105 |
| Fuel consumption (g/kw.h) | ≤243 |
| Alternator | Type | Copy Stamford-BS184E |
| Rated Output (KW/KVA) | 20KW/25KVA |
| Max Output (KW/KVA) | 22KW/27.5KVA |
| Power Factor (cos Ø) | 0.8 |
| Excitation Mode | single-bearing with SAE ,Brushless synchronous ,Three harmonic
exciting |
| AVR Model | SX460 |
| Insulation Class | H CLASS |
| IP Level (PROTECTION) | IP23 |
Q : What is your lead time ?
A : About 30 days after receiving deposit or original L/C . But if
your order with some special design ,
then the delivery time is longer .
Q : Do you offer OEM service ?
A : Yes
Q : What is your payment term ?
A : 30% T/T in advance , the rest payment before shipment . Or
irrevocable L/C .
