Ac Synchronous Brushless Double Bearing 280kw Stamford Alternator
Features
1 . Easy to be connected with power network or other ac generator.
Standard 2/3 pitch windings avoid excessive neutral current.
2 . Dynamically balanced rotors , with single or two sealed ball
bearings .
3 . Simple installation and maintenance with easy access to
terminals , rotating diodes and coupling bolts .
4 . Wide range of flange adaptor and single bearing coupling disc .
5 . Built to conform to all leading industrial standards.
Under the following conditions, generator can be at rated load
operation.
1. The altitude does not exceed 1000m.
2. Cooling air temperature 258~313K(-15°C~40°C)
3. Relative humidity does not exceed 90%.
| Model | PRIME OUTPUT(1500RPM/50HZ)400V | PRIME OUTPUT(1800RPM/60HZ)440V |
| KW | KVA | A | KW | KVA | A |
| BC164A | 6.5 | 8.1 | 11.7 | 8.2 | 10.2 | 14.8 |
| BC164B | 8.8 | 11 | 15.8 | 11 | 13.8 | 19.88 |
| BC164C | 10.8 | 13.5 | 19.4 | 13.5 | 16.9 | 24.38 |
| BC164D | 12.8 | 16 | 23 | 16 | 20 | 28.88 |
| BC184E | 18 | 22.5 | 32.4 | 23 | 28.8 | 41.5 |
| BC184F | 22 | 27.5 | 39.6 | 27.5 | 34.4 | 49.68 |
| BC184G | 25 | 31.3 | 45 | 30 | 37.5 | 548 |
| BC184H | 30 | 37.5 | 54 | 37.5 | 46.9 | 67.68 |
| BC184J | 34 | 42.5 | 61.3 | 40 | 50 | 728 |
| UC224C | 34 | 42.5 | 61.3 | 42 | 52.5 | 75.78 |
| UC224D | 40 | 50 | 72 | 50 | 62.5 | 90.28 |
| UC224E | 48 | 60 | 86.6 | 56 | 70 | 1018 |
| UC224F | 58 | 72.5 | 104.6 | 70 | 87.5 | 126.3 |
| UC224G | 68 | 85 | 122.6 | 78 | 97.5 | 140.7 |
| UC274C | 80 | 100 | 144.3 | 94 | 117.5 | 169.6 |
| UC274D | 96 | 120 | 173.2 | 110 | 137.5 | 198.4 |
| UC274E | 112 | 140 | 202 | 134 | 167.5 | 241.7 |
| UC274F | 128 | 160 | 230.9 | 152 | 190 | 274.2 |
| UC274G | 145.6 | 182 | 262.7 | 174.8 | 218.5 | 315.3 |
| UC274H | 160 | 200 | 288.6 | 196 | 245 | 353.6 |
| UC274J | 184 | 230 | 331.9 | 224.8 | 281 | 405.6 |
| UC274K | 200 | 250 | 360.8 | 239.2 | 299 | 431.5 |
| HC314C | 200 | 250 | 360.8 | 240 | 300 | 433 |
| HC314D | 240 | 300 | 433 | 288 | 360 | 519.6 |
| HC314ES | 260 | 325 | 469 | 315.2 | 394 | 568.7 |
| HC314E | 280 | 350 | 505 | 336 | 420 | 606.2 |
| HC314FS | 304 | 380 | 548.4 | 365 | 456 | 658.5 |
| HC314F | 320 | 400 | 577.3 | 384 | 480 | 692.8 |
| HC354C | 360 | 450 | 649.5 | 440 | 550 | 793.8 |
| HC354D | 400 | 500 | 721.7 | 475.2 | 594 | 857.4 |
| HC354ES | 480 | 600 | 866 | 570.4 | 713 | 1029 |
| HC354E | 480 | 600 | 866 | 570.4 | 713 | 1029 |
| HC354FS | 536 | 670 | 967 | 580 | 725 | 1046.4 |
| HC354F | 536 | 670 | 967 | 620 | 775 | 1118.6 |
| HC404B | 600 | 750 | 1082.5 | 684 | 855 | 1234 |
| HC404C | 640 | 800 | 1154.7 | 733 | 916 | 1322.5 |
| HC404D | 728 | 910 | 1313.5 | 834 | 1043 | 1504.7 |
| HC404E | 800 | 1000 | 1443.4 | 916 | 1145 | 1652.7 |
| HC404F | 904 | 1130 | 1631 | 1019 | 1274 | 1838.5 |
| HC404G | 1000 | 1250 | 1804.2 | 1109 | 1386 | 2000.9 |
1 . The rotors and stators with 100% copper wire.
2 . The silicon steel sheet we use is the products of Wugang
Brand,800 Series.which is the
most famous manufacture of steel.And its advantage is its magnetic
flux is large and its
iron loss is small.
3 . The main frame of the alternator and lead box are made of steel
4 . All the components of our factory,the stator,rotor and
excitation will be dipping lacquer twice.
5 . The rope of best nylon to be used in all the rotors and
stators.We promise the security of
our products.
6 . All the rotors should be tested by dynamic balance to go on
test of balance.
7 . Our material has a step by printing the conformal coating,it
can protect the material.
Q : Do you offer OEM service ?
A : Yes
Q : What is your payment term ?
A : 30% T/T in advance , the rest payment before shipment . Or
irrevocable L/C .
Q : What is your lead time ?
A : About 30 days after receiving deposit or original L/C . But if
your order with some special design , then the delivery time is
longer .
Q : What certificates do you have ?
A : We have CE , ISO. And we can apply for specific certificate for
different country such as SONCAP for Nigeria , CIQ for Egypt , SASO
for Saudi Arabia , etc
Q : What is your MOQ ?
A : Above 1pc
Q : Which port do you often use when export ?
A : Fuzhou Port , or as customer request .
